Chapter 8 Data Models and Dynamic Templates

network 172.20.{{ host_defaults.site_id }}.0 0.0.0.3 area {{ host_vrfs[host_vrf].tag
}}
{%          endif %}
{%          if host_vrfs[host_vrf].networks is defined %}
{%              for network in host_vrfs[host_vrf].networks %}
{%                  for value in host_vrfs[host_vrf].networks[network].value %}
 network {{ value }} area {{ network }}
{%                  endfor %}
{%              endfor %}
{%          endif %}
{%          if host_vrfs[host_vrf].default_originate is defined %}
 default-information originate always
{%          endif %}
{%      endfor %}
{%  endif %}

Static Routes

{%  if host_static_routes is defined %}
{%      for host_static_route in host_static_routes %}
{%          for route in host_static_routes[host_static_route].routes %}
{%              if host_static_route == "global" %}
ip route {{ route }}
{%              else %}
ip route vrf {{ host_static_route }} {{ route }}
{%              endif %}
{%          endfor %}
{%      endfor %}
{%  endif %}


Data model – host_vars file CORE.yml.

host_static_routes:
  global:
    routes:
    - "0.0.0.0 0.0.0.0 172.20.205.114 name Management_Outside_to_Firewall"
    - "192.168.100.0 255.255.192.0 172.20.200.100 name Switch_Management_Traffic"
    - "192.168.120.0 255.255.255.0 172.18.100.50 name Load_Balancer"
    - "192.168.130.0 255.255.224.0 192.168.200.132 name WAN_Management_to_Firewall"
    - "192.168.140.0 255.255.224.0 192.168.220.132 name WAN_WAPs_to_Firewall"

  GREEN_Zone:
    routes:
    - "192.168.0.0 255.252.0.0 192.168.1.100 name WAN GREEN_Zone_Transit_to_Firewall"
    - "192.168.3.0 255.255.255.0 192.168.200.100 name Voice_Transit_to_Firewall"

  WAN_Zone:
    routes:
    - "0.0.0.0 0.0.0.0 172.20.205.146 name WAN Traffic_to_AWS"
    - "10.0.0.0 255.0.0.0 172.20.205.146 name WAN Traffic to AWS"
    - "192.168.0.0 255.240.0.0 172.20.205.146 name WAN Traffic to AWS"
