Chapter 4 Where to Start with Network Automation?

o QoS model for legacy multi-layer switching (MLS) QoS. o Applied at access layer on 3750 platform.

 12_IOS_6k_qos.j2: o QoS model specific to the core or Catalyst 6000 platform.

 13_IOS_mqc_qos.j2: o Modern modular QoS CLI (MQC) model. o Applied at both distribution layer on Catalyst 4500 platform and access layer on Catalyst

3850 platform.  14_IOS_prefix_list.j2: o Standard prefix list commands. o Used on core or distribution layers.

 15_IOS_route_maps.j2: o Route maps commands. o Applied at core or distribution layers.

 16_IOS_aaa_rsa.j2: o Authentication, authorization, auditing. o RSA authentication. o Applied across the enterprise.

 17_IOS_dot1x.j2: o 802.1x related configurations. o Applied at the access layer.

 18_IOS_dot1x_radius.j2: o 802.1x RADIUS server configurations. o Applied at the access layer.

 19_IOS_vrfs.j2: o Virtual Route Forwarding (VRF) related configurations. o Applied at the core and distribution layers. o Sample:

{% if platform_defaults.type == CORE or platform_defaults.type == DIST %}
{%     for host_vrf in host_vrfs %}
{%         if host_vrf == "global" %}
{%         else %}
vrf definition {{ host_vrf }}
{%         endif %}
{%         if host_vrf == "global" %}
{%         else %}
 vnet tag {{ host_vrfs[host_vrf].tag }}
  address-family ipv4
  exit-address-family
{%         endif %}
{%         if host_vrfs[host_vrf].multicast is defined %}
ip multicast-routing vrf {{ host_vrf }}
